This is a 4-Channel DC 24V Relay Module High/Low-Level Triggering Optocoupler Isolation. Using a high-power relay, the maximum control load is DC 30V 30A / AC 250V 30A. With each optocoupler isolation, anti-interference ability. In line with international safety standards, the control area and the load area with isolation slot. Each channel has a relay on LED indication

Application:

1. PLC automation equipment control
2. Industrial system control
3. Logistics network control
4. Home intelligent product control
5. Electronic enthusiasts to develop experiments
6. All kinds of circuit modification

Features:

1. Using a high-power relay, the maximum control load is DC 30V 30A / AC 250V 30A.
2. With each optocoupler isolation, anti-interference ability.
3. In line with international safety standards, the control area and the load area with isolation slot.
4. Each channel has a relay on the LED indication.

Module Interface Description:

1. DC +: DC power supply positive
2. DC -: DC power supply module negative
3. IN: Signal input terminal(support High/Low-Level switch freely)
4. Normally open (NO): Relay normally open
5. Common terminal (COM): Relay common
6. Normally closed terminal (NC): relay normally closed terminal

Package includes:

1 x 4-Channel DC 24V Relay Module High/Low-Level Triggering Optocoupler Isolation

This is AC To AC SSR-100AA Solid State Relay Module 80-250VAC/24-380VAC 100A. A solid-state relay (SSR) is an electronic switch, which, unlike an electromechanical relay, contains no moving parts. The types of SSR are photo-coupled SSR, transformer-coupled SSR, and hybrid SSR. A photo-coupled SSR is controlled by a low voltage signal which is isolated optically from the load.

The control signal in a photo-coupled SSR typically energizes an LED which activates a photo-sensitive diode. The diode turns on a back-to-back thyristor, silicon-controlled rectifier, or MOSFET transistor to switch the load.

This particular SSR can switch current loads of up to 100A with an 80-250VAC input and a zero cross trigger control method. Each one of these relays is equipped with four screw terminals (for use with ring or fork connectors) and a plastic cover that slides over the top of the relay to protect the terminals.

Features:

1. Long service life and high reliability
2. Reduced electromagnetic interference
3. Highly reliable, compact size designed to offer users maximum simplicity.

Package Includes:

1 x 80-250V SSR-100AA Solid State Relay

This is a 2 Channel 3-24V Solid State Relay Module. A solid-state relay (SSR) is just what it sounds like; an IC that acts like a mechanical relay. They allow you to control high-voltage DC loads from lower voltage DC control circuitry. They accomplish this by using infrared light as the ‘contact,’ a solid-state relay is really just an IR LED and a photo Triac sealed up into a little box. Solid-state relays have several advantages over mechanical relays.

A Solid State Relay is similar to a mechanic relay where it can be controlled through a digital signal. Solid State Relay generates no noise and has a much longer lifespan compared to the traditional mechanic relay.

When the input logic voltage is applied to the coil, the NC will disconnect from the COM breaking the conductivity between the two. At the same time, the NO will connect with the COM allowing conductivity between them. Depending on your wiring this will turn on or off the connected load.

Input Parts :

1. DC+: connected to VCC (Supply power according to relay voltage)
2. DC-: connected to GND
3. DC+: connect power positive
4. DC-: connect power negative
5. CH1: relay module signal trigger point (Effective low-level trigger)
6. CH2: relay module signal trigger point (Effective low-level trigger)

Features:

1. 2-channel 2 AMP Solid State Relay board.
2. Control 4 loads of up to 2 amps each at 50 V DC.
3. Good for lighting, Holiday displays, etc.
4. Has been assembled, and the electrical test passed.
5. Led indicator for each relay.
6. Use it to control various appliances and other equipment with a large current.
7. It can be controlled directly by a Microcontroller

Specifications:

1. Part Number: H3MB-052DP
2. Power supply:3-24VDC/160mA
3. Switching Voltage (VAC):50@2A
4. Isolation: Phototriac
5. Zero Cross: Yes
6. Length (mm):35
7. Width (mm):25
8. Height (mm):24
9. Weight (gm):18

Package Includes:

1 x 2 Channel 3-24V Relay Module Solid State High-Level SSR DC Control DC with Resistive Fuse

This is a 2 Channel 12V Solid State Relay Module. A solid-state relay (SSR) is just what it sounds like; an IC that acts like a mechanical relay. They allow you to control high-voltage AC loads from lower voltage DC control circuitry. They accomplish this by using infrared light as the ‘contact,’ a solid-state relay is really just an IR LED and a photo Triac sealed up into a little box. Solid-state relays have several advantages over mechanical relays.

A Solid State Relay is similar to 2 Channel 12V Relay Module Solid State High-Level SSR DC Control 250V 2A with Resistive to a mechanic relay where it can be controlled through a digital signal. Solid State Relay generates no noise and has a much longer lifespan compared to the traditional mechanic relay.

When the input logic voltage is applied to the coil, the NC will disconnect from the COM breaking the conductivity between the two. At the same time, the NO will connect with the COM allowing conductivity between them. Depending on your wiring this will turn on or off the connected load.

Features:

Input Parts :

1. DC+: connected to VCC (Supply power according to relay voltage)
2. DC-: connected to GND
3. CH1: relay module signal trigger point (Effective high-level trigger)
4. CH2: relay module signal trigger point (Effective high-level trigger)

Features:

1. 2-channel 2 AMP Solid State Relay board.
2. Control 2 loads of up to 2 amps each at 240 V AC.
3. Good for lighting, Holiday displays, etc.
4. Has been assembled, and the electrical test passed.
5. Led indicator for each relay.
6. Use it to control various appliances and other equipment with a large current.
7. It can be controlled directly by a Microcontroller

Specifications:

1. Part Number: G3MB-202P
2. Power supply:12VDC/160mA
3. Switching Voltage (VAC):240@2A
4. Isolation: Phototriac
5. Zero Cross: Yes
6. Length (mm):50
7. Width (mm):30
8. Height (mm):24
9. Weight (gm):18

Package Includes:

1 x 2 Channel 12V Relay Module Solid State High-Level SSR DC Control 250V 2A with Resistive Fuse

433MHz 24V 1 Channel Relay Module Wireless Remote Control Switch is controlled by an intelligent microprocessor, which can be used in the control of garage door, lighting control, curtain control, door control system, etc. Easy to install, small size, safe and reliable.

Note: Remote Control included in the package does not come with a Battery due to Air Express Shipping Limitations. You have to buy the battery separately. Click Here

Features:

1. Operation Manual: Press the learn button for 2 or 3 seconds, lights out (that has entered the state of learning), Release the learning button, press any key of the remote control, and the indicator light flashes 5 times to show the success of the study. Note: The controller can learn the fixed code/learning code, a total of 16 different encodings, arbitrary button remote control, and beyond will be cleared in the early learning of remote control.
2. Removal method: Continue to hold down the learning button for about 8 seconds. The indicator light is extended from extinction to success.
3. Work mode switching: Connect a 12V DC output: the learning of the single remote control switch 12V input, connect a 12V DC power supply, the output from 12V positive public end, often beginning the positive on the output side of the light bulb, the bulb of the cathode received power of the cathode, a simple control light bulb circuit is designed.

Package Includes:

1 x 433MHz 24V 1 Channel Relay Module

This 12 V 6Channel SSR Solid State Relay Module 250V 2A Output with Resistive Fuse is based on the Omron G3MB -202P SSR relay which can control up to 2A at 240VAC. This is a 6 Channel SSR relay module, each relay channel has 3 separate terminals, NO (Normal Open), COM (Common), NC (Normal Closed).

A Solid State Relay is similar to a mechanic relay where it can be controlled through a digital signal. Solid State Relay generates no noise and has a much longer lifespan in compared to the traditional mechanic relay.

When the input logic voltage is applied to the coil, the NC will disconnect from the COM breaking the conductivity between the two. At the same time, the NO will connect with the COM allowing conductivity between them. Depending on your wiring this will turn on or off the connected load.

Input parts :

1. DC+: connect power positive
2. DC-: connect power negative
3. CH1: relay module signal trigger point (Effective low-level trigger)
4. CH2: relay module signal trigger point (Effective low-level trigger)
5. CH3: relay module signal trigger point (Effective low-level trigger)
6. CH4: relay module signal trigger point (Effective low-level trigger)
7. CH5: relay module signal trigger point (Effective low-level trigger)
8. CH6: relay module signal trigger point (Effective low-level trigger)

Features :

1. Has been assembled, and the electrical test passed.
2. Led indicator for each relay.
3. Use it to control various appliances and other equipment with a large current.
4. It can be controlled directly by a Microcontroller
5. Input control signal voltage:
   1. 0-2.5V status low level, relay OFF
   2. 3-5V status high level, relay ON

Specifications:

1. Part Number: G3MB-202P
2. Working current(mA):12.5
3. Trigger Current (mA):2
4. Trigger Voltage (VDC):12
5. Switching Voltage (VAC):5060@2A
6. Max. Load:2A @5060V AC
7. Length (mm):80
8. Width (mm):50
9. Height (mm):24
10. Weight (gm):49

Package Includes:

1 x 6 Channel 12V Relay Module Solid State Low Level SSR DC Control 250V 2A with Resistive
