Conductivity Sensor, 100 µS/cm to 200 mS/cm, 100 Hz to 10 kHz, 0.3 mA, 4 Electrode

LFS1305 CLASS C / F0.6 Conductivity Sensor 100 µS/cm to 200 mS/cm 100 Hz to 10 kHz 0.3 mA 4 Electrode  Conductivity Sensor can be used for various conductivity measurement applications.

Features:

1. Wide conductivity and temperature range ▪ Excellent long-term stability
2. Fast response time
3. Integrated RTD for temperature measurement and /or compensation
4. Optimal accuracy
5. 4 electrode measurement
6. Resistance to various chemicals

Specifications:

1. Conductivity range: 100 µS/cm to 200 mS/cm
2. Cell constant4): typical 0.86 cm-1
3. Nominal resistance: 1000 Ω at 0 °C
4. Measurement frequency range: 100 Hz to 10 kHz
5. Maximum excitation voltage (between pin 1 and pin 6): < 0.7 Vpp (Electrolysis of the analyte has to be avoided)
6. Operating temperature range: -30 °C to +100 °C
7. Temperature sensor: Pt1000
8. Temperature coefficient (Pt1000): 3850 ppm/K
9. Measuring current (Pt1000)5): 0.3 mA
10. Temperature sensor accuracy (dependent on temperature range): IEC 60751 F0.6 C (IST AG reference)
11. Connection: Pt/Ni wires, Ø 0.2 mm
12. Dimensions (L x W x H / H2 in mm): 12.9 ±0.3 x 5.5 ±0.3 x 0.65 ±0.1 / 1.2 ±0.3

Package Includes:

1 x LFS1305 CLASS C / F0.6 Conductivity Sensor 100 µS/cm to 200 mS/cm 100 Hz to 10 kHz 0.3 mA 4 Electrode
