Chipsee EPC-A72-70-C Industrial embedded 7 Inch PC with Android OS

The EPC-A72-70-C (CS10600R070E) is a high-quality industrial embedded computer, that features a 7 inch LCD with a five-point capacitive touchscreen, an ARM dual Cortex-A72 (1.8GHz) plus Quad Cortex-A53 (1.4GHz) processor with 4GB DDR3 RAM and 16GB eMMC Flash, 1Gb Ethernet, 1 USB 2.0 port, 1 USB 3.0 port, 1 Type-C port, 1 LAN port, 4 RS232 connectors, and 2 RS485 connectors, as well as a 3.5mm audio connector.

Features:

1. The EPC-A72-70-C has a 7’’ five-point capacitive touch screen, with a 1024×600 resolution
2. Five-point capacitive touchscreens offer stable and accurate control over the device
3. Capacitive touchscreens offer great image clarity
4. They are also very durable and resistant to environmental contaminants like dust and water
5. The EPC-A72-70-C has one channel 1Gb Ethernet port and one TF (uSD) card connector
6. This device supports a TF card of up to 32GB

Specifications:

1. Form-factor: Embedded
2. Display Size (inch.): 7.0
3. CPU: Rockchip RK3399
4. RAM: 4GB DDR3
5. External storage: TF (microSD) Card Slot
6. FLASH: 16GB
7. Resolution: 1024 X 600
8. Brightness (NIT): 500 NIT
9. Touch Screen: Capacitive
10. Bluetooth: Onboard Bluetooth
11. WiFi: Onboard WiFi
12. HDMI: 1x HDMI
13. Ethernet: 1x LAN 1000M
14. USB: 1x USB 3.0 HOST, 1x USB Type-C, 1x USB 2.0 HOST
15. GPIO: 8x GPIO
16. RS232+RS485: Default 4xRS232 and 2x RS485 (1 debug port)
17. Buzzer: Yes
18. Power Consumption: 8W
19. Power Input: 12~36V DC
20. Working Temperature: -20°C ~ 70°C
21. Mounting Method: Embedded Mounting
22. Preinstalled OS: Android 7.1, Debian 10
23. Weight:345 g
24. Dimensions: 190 × 107 × 27.7 mm

Connection Diagram:

Packages Includes:

1 x Chipsee EPC-A72-70-C Industrial embedded 7 Inch PC with Android OS
