Description

The DF40 series Board-to-Board and Board-to-FPC Connector with a space-saving design that has a minimum connector width, yet still retains a sufficient vacuum area for easy pick-and-place mounting. In addition to its space-saving design, several stack heights are available and add versatility to any application. Stack heights – 1.5, 2, 2.5, 3, 3.5 and 4mm. Despite its small stature and low profile, the contacts deliver strong contact forces and an effective mating length of 0.45mm on the 1.5mm stacking height. This connector utilizes a locking system that prevents accidental unmating issues and emits a clear tactile click to ensure that mating has been completed. The use of guide ribs allows 0.33mm of self-alignment on this connector. Both sides of the connector have been reinforced with the addition of shock-absorbing ribs. Nickel-plated barriers were added to protect the contact areas from potential solder wicking.

Features:

1. High-density mounting
2. Multiple stack height options
3. High contact reliability
4. Reinforced structure with shock-absorbing ribs
5. Solder wicking prevention
6. Contamination resistant design
7. High-speed signal with noise prevention
8. Minimum Width: 3.38mm

Specifications:

1. Mezzanine Connector Type: Receptacle (View Associated Connectors)
2. Pitch Spacing: 0.4mm
3. No. of Rows: 2Rows
4. No. of Contacts: 100Contacts
5. Connector Mounting: Surface Mount
6. Contact Material: Phosphor Bronze
7. Contact Plating: Gold Plated Contacts
8. Product Range: DF40

Package Includes:

1 x DF40C-100DS-0.4V(51)-CONNECTOR, STACKING, RCPT, 100
