2100HT-221V-RC 2138 High Current Toroid Inductors

2100HT-221V-RC 2138 High Current Toroidal DIP Inductor is a passive electronic device widely used in electronic circuits. It is an insulated coil that is a wire wound on a ring-shaped form that is made of different materials, such as powdered iron, ferrite, or another material.

A toroidal inductor is mostly used where large inductance is required. Toroidal inductors have more inductance per turn and can carry more current than solenoids with a core of similar material and size

Applications:

1. Tuning circuits.
2. Sensors.
3. Store energy in a device.
4. Induction motors.
5. Transformers.
6. Filters.
7. Chokes.
8. Ferrite beads

Note: Actual product can vary from the shown image

Features:

1. High-temperature rating up to +200 °C
2. Low magnetic radiation
3. High current capacity
4. Horizontal or vertical mount available
5. Low cost
6. Operating temperature: -55 to +200 °C

Packages Includes:

1 x 2100HT-221V-RC 2138 High Current Toroid Inductors
