5A CNC DC-DC Stepdown, Power Supply, Module

ZK-J5X is a DC adjustable constant voltage constant current step down power supply module with an LCD display.HD display input voltage and output voltage, current, power, and display status.Adjustable stable output voltage and current.Set output current to meet the demand. It can be used as an ordinary buck power supply module, charger, and LED constant current driver. Simple and efficient, practical.

Features:

1. High voltage resistant terminal
2. With a high-quality acrylic shell
3. Support complete disability output
4. Support anti-reverse protection
5. Support short circuit protection
6. Support enable output
7. LCD screen HD display

Specifications:

1. Working Voltage: DC 6.5V-36V
2. Output Voltage:DC 1.2V-32V
3. Output Current:5A
4. Output Power:75W(75W need heat sink;50W is for 3.5A)
5. Voltage Display Range:1.2~32V
6. Voltage Display Precision:+/-0.1V
7. Voltage Display Resolution:0.05V
8. Current Display Range:0~5A
9. Current Display Precision:+/-0.05A
10. Voltage Display Resolution:0.005A
11. Conversion efficiency: About 94%
12. Working current:30mA
13. Working Temperature range:-20°~85°
14. Working Humidity range:0%-95%RH
15. Size with shell:70.5*48.4*30mm

Package Includes:

1  x 5A CNC DC-DC Stepdown Power Supply Module
