6S 22.2V 18650 Lithium Battery Equalizer Board 25.2V Polymer Battery Equalizer Board Connector

PCM or PCB ( protection circuit module or board ) is the “heart” of Lithium battery pack. It will protect Lithium battery pack from overcharging, over-discharging and over-drain, therefore it is the must to have to avoid Lithium battery pack from explosion, fire and damage.

A Battery Equalizer is a specialized DC-DC converter, designed to convert electrical power from one voltage to another at high efficiency. They’re used to balance battery loads in dual voltage systems.

How Lithium-ion Battery Equalizer Board work. In active balancing, energy is drawn from the most charged cell and transferred to the least charged cells, usually through capacitor-based, inductor-based or DC-DC converters. Active balancing attempts to redistribute energy from cells at full charge to those with a lower state of charge.

Solder Joint Description: B – Connect the negative of the battery pack；
B1 is connected to the middle of the battery 1 and the battery 2;
B2 is connected to the middle of the battery 2 and the battery 3;
B3 is connected to the middle of the battery 3 and the battery 4;
B4 is connected to the middle of the battery 4 and the battery 5;
B5 is connected to the middle of the battery 5 and the battery 6;
B6 Connect the battery pack positive；

Application:

1. E-Bick.
2. Battery packs.
3. Power Banks.

Features:

1. With Balance.
2. Overcharge protection.
3. Over-discharge protection.
4.  18650 Lithium Battery Equalizer Board.

Specification:

1. Battery types: 18650 Lithium Battery
2. Type: Voltage Regulator.
3. Supply Voltage: 25.2v
4. Dissipation Power:18650 Lithium Battery Balanced Function Board.
5. Application: 8s Lithium Battery Balanced Function Board.
6. No. resistors: 6
7. Values of resistor: 620R

Package Includes:

1 x 6S 22.2V 18650 Lithium Battery Equalizer Board 25.2V Polymer Battery Equalizer Board Connector
