BG120-10-A-0-N-D-RECEPTACLE, BOARD TO BOARD, 2R

The BG120-10-A-0-N-D is a 10-contact 2.54mm black straight Board-to-board Socket with gold flash (standard) plated phosphor bronze contacts and a UL94V-0 polyamide nylon 6T standard insulator. The BG120 series receptacle has tuning fork type contacts, surface type PCB mount, and dual entry type. LCP and Nylon 6T are suitable for IR reflow, wave and manual solder.

Features:

1. No locating peg
2. 3A Current rating
3. 20mR Maximum contact resistance
4. 1000MR Minimum insulation resistance
5. 600VAC Dielectric withstanding voltage
6. 0.64mm Mates with square pin size

Specifications:

1. Connector Systems: Board-to-Board
2. Pitch Spacing: 2.54mm
3. No. of Rows: 2Rows
4. No. of Contacts: 10Contacts
5. Connector Mounting: Surface Mount
6. Product Range: BG120
7. Contact Material: Phosphor Bronze
8. Contact Plating: Gold Plated Contacts

Package Includes:

1 x G120-10-A-0-N-D-RECEPTACLE, BOARD TO BOARD, 2R
