Connectwell CSTSN4U 10 sq. mm Stud Type Terminal Block (Grey)

SKU: RZ24340134 Brand: Connectwell Category: General

₹ 57.96

Out of Stock

Buy Connectwell CSTSN4U 10 sq. mm Stud Type Terminal Block (Grey) online, Order today to get instant delivery in all over india.

Bulk Discount Pricing

Quantity	Discount	Price / Unit
5 – 10	2%	₹ 56.80
11 – 30	3%	₹ 56.22
31 – 50	4%	₹ 55.64
51 – 100	5%	₹ 55.06

Out of Stock

You're on the list! We'll email you when this product is back in stock.

Enter your email to be notified when this product is available again.

Why Buy From Us

Fast Shipping

Quick dispatch on all orders

Secure Payment

100% safe transactions

GST Invoice

Available on all orders

Easy Returns

7-day return policy

Expert Support

Always here to help

Product Details

Brand Connectwell

Category General

Subcategory General

SKU RZ24340134

The Connectwell CSTSN4U is a 10 sq. mm Stud Type Terminal Block in Grey color with Universal Mounting Possibility. These Terminal Blocks are recommended for applications in which the connections are subjected to high vibrations. The wire is crimped to a ring/fork type Lug (Ferrule) and screwed onto the Terminal Block's flat current bar. Terminal Blocks are available in sizes ranging from 1.5 to 10 sq mm. External shorting links can be used to achieve cross-connection. To completely encase these assemblies, it is advised to use Protective Covers made of transparent plastic.

Datasheet

Specifications

Rated Voltage	1000V
Housing Material	Polyamide
Rated Current	57A
Tightening Torque	1.2 Nm
Product Function	Feed Through
Wire Entry Orientation	Side Entry
Mounting Possibilities	DIN 32/DIN 35/DIN 35-15 Rail
Screw Size	M4
Operated by	Nut Driver
Rated Surge Voltage	8 KV
Pollution Degree	3

Dimensions

Height with DIN 32 rail	46.3mm
Height with DIN 35 * 15mm rail	48mm
Height with DIN 35 * 7.5mm rail	40.7mm
Length	50mm
Width(Thickness)	17mm
Country of Origin	China
