DAC0808LCN 8 Bit D/A Converter DIP-16 Package

DAC0808LCN is an 8 Bit converter its DAC means its digital to analog converter. Featuring a full scale output current settling time of 150 ns while dissipating only 33 mW with ±5V supplies. No reference current (IREF) trimming is required for most applications since the full scale output current is typically ±1 LSB of 255 IREF/256. Relative accuracies of better than ±0.19% assure 8-bit monotonicity and linearity while zero level output current of less than 4 µA provides 8-bit zero accuracy for IREF>=2 mA. The power supply currents of the DAC0808 is independent of bit codes, and exhibits essentially constant device characteristics over the entire supply voltage range.

Features:

• Its full scale current match is -+ 1 LSB Type
• Its settling time is too fast
• Its non inverting Digital inputs as TTL and CMOS
• Its low power consumption is 33mW on 5V
• It has total 16 pin

Specifications:
