Degson 5 Pin 5.08 mm Pitch Pluggable type PCB Terminal Block

Degson 5 Pin 5.08 mm pitch Pluggable type PCB terminal block is a type of electronic component that provides a secure and reliable way to connect wires to printed circuit boards (PCBs). The “5 pin” refers to the number of connections available on the terminal block. This means that up to eight wires can be connected to the terminal block.

The “5.08 mm pitch” refers to the distance between each pin or connection. In this case, it is 5.08 mm, which means that each pin is spaced 5.08 mm apart from the next one. The “pluggable type” means that the terminal block is designed to be easily plugged and unplugged. This allows for easy maintenance and replacement of components, without the need for soldering or other complex procedures.

The Degson 2EDGK-5.08-05P 5Pin 5.08mm pitch Pluggable type PCB terminal block is a versatile and convenient component that can be used in a wide range of electronic applications.

Specifications and Features:

1. Number of pins: 5
2. Pitch: 5.08 mm
3. Rated voltage: 320V
4. Rated current: 20A
5. Wire range: 28-14 AWG
6. Contact resistance: 40mΩ max
7. Operating temperature range: -40°C to 105°C
8. Material: Housing: PA44, UL94V-0
9. Contact: Brass, Tin-plated

Package Includes:

1 x Degson 5 Pin 5.08 mm pitch Pluggable type PCB terminal block
