HC-06 6-Pin Bluetooth Module

SKU: RZ24339749 Category: Wireless & Communication

₹ 558.90

Out of Stock

Buy HC-06 6-Pin Bluetooth Module online, Order today to get instant delivery in all over india.

Bulk Discount Pricing

Quantity	Discount	Price / Unit
5 – 10	2%	₹ 547.72
11 – 30	3%	₹ 542.13
31 – 50	4%	₹ 536.54
51 – 100	5%	₹ 530.95

Out of Stock

You're on the list! We'll email you when this product is back in stock.

Enter your email to be notified when this product is available again.

Why Buy From Us

Fast Shipping

Quick dispatch on all orders

Secure Payment

100% safe transactions

GST Invoice

Available on all orders

Easy Returns

7-day return policy

Expert Support

Always here to help

Product Details

Category Wireless & Communication

Subcategory Bluetooth & NRF Modules

SKU RZ24339749

The HM-06 Bluetooth module is intended for short-range wireless data communication between two microcontrollers or systems. This is the cheapest and most flexible method for wireless data transmission, and it can even transmit files at speeds of up to 2.1 Mb/s. The UART interface is used to communicate with the HC-06 module. The working current is matched to 30 mA, matching the communication for 8 mA.

Pinout:

KEY
VCC
GND
TXD
RXD
STATE

Applications

Engineering Projects
Robotic
Computer Peripherals

Specifications

Model	HC-06
Type	Bluetooth Module
Bluetooth Protocol	Bluetooth V2.0 Protocol
Power Level	Class 2 (+6dbm)
Operating Voltage Range	+3.3V to +6V
Operating Temperature Range	-20ºC to +55ºC
Operating Current	40mA
Safety Feature	Authentication and encryption
Size(LHD) (mm)	39163.5 (mm)
Country of Origin	China
