HT12E 12-Bit Encoder IC (HT12E IC) DIP-18 Package

SKU: RZ24344657 Category: General

₹ 57.50

Out of Stock

Buy HT12E 12-Bit Encoder IC (HT12E IC) DIP-18 Package online, Order today to get instant delivery in all over india.

Bulk Discount Pricing

Quantity	Discount	Price / Unit
5 – 10	2%	₹ 56.35
11 – 30	3%	₹ 55.78
31 – 50	4%	₹ 55.20
51 – 100	5%	₹ 54.63

Out of Stock

You're on the list! We'll email you when this product is back in stock.

Enter your email to be notified when this product is available again.

Why Buy From Us

Fast Shipping

Quick dispatch on all orders

Secure Payment

100% safe transactions

GST Invoice

Available on all orders

Easy Returns

7-day return policy

Expert Support

Always here to help

Product Details

Category General

Subcategory General

SKU RZ24344657

HT12E is a CMOS technology-based 12-bit Encoder. It is generally used with RF communication system applications. 12-bit Encoders can encode up to 2^12 two-state data which is transmitted via RF transmitter to receiver. This encoded data consists of 8 address bits and 4 data bits. For proper communication, HT12E is should be used with HT12D in the same address and data formate. This device consists of one data output pin that transmits the encoded data from the RF transmitter channel. Two oscillators pin (OSC1, OSC2) can decide the oscillation frequency of the Encoder by using an oscillator resistor. Active Low Trigger Enable pin (TE’) can trigger the transmission or vice versa.

The HT12E ICs have an operating range of VCC from 2.4 V to 12 V. Maximum current consumption is 0.3 mA through Icc and output sink and source current is 1.6 mA. The recommended operating voltage is 5 V.

Pin Configuration

Address Pin (A[0:7])	1, 2, 3, 4, 5, 6, 7, 8
Data Pin (A[8:11])	10, 11, 12, 13
Oscillator I/O Pin (OSC1, OSC2)	16, 15
Valid Transmission Pin (TE')	14
Data Input Pin (DOUT)	17
Power Supply (VDD)	18
Ground (VSS)	9

Features

Operating voltage 2.4V~12V.
Low power and high noise immunity CMOS technology.
Low standby current: 0.1A (Typ.) at VDD=5V.
Data code has a positive polarity.
HT12A with a 38kHz carrier for the infrared transmission medium.
Minimum transmission word Four words for the HT12E.
The built-in oscillator needs only a 5% resistor.
Minimal external components.
12-bit Encoder IC to be used with HT12D
Encoded data has 4 Data bits and 8 Address bits
Commonly used for RF and IR wireless transmission
Wide supply voltage ranges from 2.4V to 12V, typically 5V is used
Low standby current of 0.1uA at Vcc=5V
Available in 16-pin DIP, 20-pin SOP

Applications

Burglar alarm system.
Smoke and fire alarm system.
Garage door controllers.
Car door controllers.
Car alarm system.
Security system.
Cordless telephones.
Other remote-control systems.

Specification

Operating Voltage Range	2.4 V to 12 V
Technology	CMOS
Package	DIP−18
Output Current	1.6 mA
Powering Current	0.3 mA
Temperature Range	-50 °C - 125 °C

Pin Description

Pin 1 - 8	These are the 8-bit address bits, which are used to protect your data. We should set the bits in the same pattern on Encoder and Decoder IC to pair them
Pin 9	Connected to the Ground of the circuit
Pin 10 - 13	These four pins are used to send data, the data encoded here will be decoded on HT12D IC sharing the same address bits
Pin 14	This pin has to be connected to the ground (0V) to enable the Transmission
Pin 15 & 16	The IC has a built-in oscillator. This oscillator can be used by connecting these two pins through a 1 M Resistor
Pin 17	The Encoded 12-bit output data can be obtained from this pin
Pin 18	This pin powers the IC, typically +5 V is used. Can range from 2.4 V to 12 V
Country of Origin	China
