Kamoer NKP-DA-B08 24V DC Brushed Motor Peristaltic Pump

When pumping liquids and no direct contact with the liquid is required, the all-new range of peristaltic pumps from kamoer offers a simple solution. Unlike most pumps, peristaltic pumps squishes a silicone tube to produce the pump action instead of impelling it directly, thus no direct contact with the liquid. This pump requires a 24V DC supply and can produce a flow rate of up to 580ml per minute. If speed control is required we suggest using a simple PWM signal

.

Applications:

1. Experiment
2. Filling packaging
3. Laboratory
4. Research institutes
5. Food industry

Features:

1. High flow
2. High negative pressure
3. Easy to maintenance
4. Chemical stability
5. Long life
6. High repeatability

Specifications:

1. Model: NKP-DC-S08
2. Motor: DC motor
3. Voltage: 24V
4. Flow: 24V Aprox 580ml/min
5. Tube: Neoprene tube/Silicone tube
6. Rotor: 3 rotors
7. Pump head: Engineering plastics
8. Pump body: PA
9. Installation method: Through plate fixation and L plate installation
10. Temperature: 0~40℃
11. Humidity: Less than 80%

Packages includes:

1 x Kamoer NKP-DA-B08 24V DC Brushed Motor Peristaltic Pump
