MCSJK-6NC1-16.00-25-B – MULTICOMP PRO

MCSJK-6NC1-16.00-25-B 16 MHz 25 ppm SMD CMOS / TTL 5 V Crystal Oscillator

Application
Used in Wireless communication, FC-HBA, PC, LCDM, Server, SONET, Telecommunications, etc.

Features:

1. High precision characteristic covering up to wide frequency range
2. Supply voltage: 5V and 3.3V supply model available
3. 3-state function
4. Automatic mounting and reflow soldering
5. High stability, low jitter, low power consumption
6. Package size: 7mm ×5mm × 1.3mm

Specifications:

1. Output Type : TTL/CMOS (6NC1), CMOS (6NC2)
2. Output Load : 15pF
3. Oscillation Mode : Fundamental / 3rd Overtone
4. Supply Voltage : 3.3V, 5V
5. Frequency Range : 1 ~ 78MHz
6. Frequency Stability : ±25ppm
7. Operating Temperature Range : -20°C to +70°C
8. Storage Temperature Range : -55°C to +125°C
9. Voltage Vol (Max.) / Voh (Min.) : 0.1VDD / 0.9VDD
10. Rise(Tr) / Fall(Tf) Time : 8ns Max.
11. Supply Current : 20mA Max.
12. Symmetry : 40 ~ 55%, 40 ~ 60%
13. Start-up Time : 5ms Max.
14. Phase Jitter (12kHz ~ 20MHz) : 1ps Max.
15. Aging (at 25°C) : ±3ppm/Year Max.
16. Size: 7mm x 5mm.

Note: For more technical details go through the datasheet in the attachments section

Package Includes:

1 x MCSJK-6NC1-16.00-25-B 16 MHz 25 ppm SMD CMOS / TTL 5 V Crystal Oscillator
