Raspberry Pi Pico W

This is a Raspberry Pi Pico W Board. Each product is powered by the RP2040, a Raspberry Pi-designed chip with two ARM Cortex-M0 + cores clocked at 133MHz, 256KB RAM, 30 GPIO pins, and a variety of interfacing options. This is paired with 2MB of onboard QSPI Flash memory for storing code and data. The Raspberry Pi Pico W has an onboard buck-boost SMPS that can generate 3.3V (to power the RP2040 and external circuitry) from a wide range of input voltages (1.8 to 5.5V). This gives you a lot of options for powering the unit, such as a single lithium-ion cell or three AA cells in series. Battery chargers can be easily integrated into the Pico W power chain as well.

Features:-

• RP2040 microcontroller with 2MB of flash memory
• On-board single-band 2.4GHz wireless interfaces (802.11n)
• Micro USB port for power and data (and for reprogramming the flash)
• Exposes 26 multi-function 3.3V general purpose I/O (GPIO)
• It can be surface-mounted as a module
• 3-pin Arm serial wire debug (SWD) port
• Simple yet highly flexible power supply architecture
• High quality, low cost, high availability

Package Includes:

1 x Raspberry Pi Pico W
