Seeed Studio Grove – 16 x 2 LCD (Black on Red)

Grove – 16 x 2 LCD is a perfect I2C LCD display for Arduino and Raspberry Pi with high contrast and easy deployment. 16×2 means two lines and each line has 16 columns, 32 characters in total. With the help of Grove I2C connector, only 2 signal pins and 2 power pins are needed. You don’t even need to care about how to connect these pins. Just plug it into the I2C interface on Seeeduino or Arduino/Raspberry Pi+baseshield via the Grove cable. There won’t be complicated wiring, soldering, worrying about burning the LCD caused by the wrong current limiting resistor.

Features:

1. Display construction: 16 Characters * 2 Lines
2. Display mode: STN
3. On board MCU
4. I2C-bus interface
5. Support English and Japanese fonts

Specifications:

1. Model: 16 x 2 LCD
2. Voltage: 3.3V/5V
3. Interface: I2C
4. Backlight color: Red
5. Font color: Black
6. Dimensions: 8 x 4 x 1mm
7. Weight: 33g

Packages Includes:

1 x Seeed Studio Grove – 16 x 2 LCD (Black on Red)
