STM32F103C6T6 Minimum System ARM Core STM32 Development Board

SKU: RZ24344142 Category: General

₹ 404.80

Out of Stock

Buy STM32F103C6T6 Minimum System ARM Core STM32 Development Board online, Order today to get instant delivery in all over india.

Bulk Discount Pricing

Quantity	Discount	Price / Unit
5 – 10	2%	₹ 396.70
11 – 30	3%	₹ 392.66
31 – 50	4%	₹ 388.61
51 – 100	5%	₹ 384.56

Out of Stock

You're on the list! We'll email you when this product is back in stock.

Enter your email to be notified when this product is available again.

Why Buy From Us

Fast Shipping

Quick dispatch on all orders

Secure Payment

100% safe transactions

GST Invoice

Available on all orders

Easy Returns

7-day return policy

Expert Support

Always here to help

Product Details

Category General

Subcategory General

SKU RZ24344142

STM32F103C6T6 Development Board is a low-cost Minimum System Development Board for ARM Microcontroller STM32F103C6T6. It has an onboard Mini USB interface, you can give the board power supply and USB communication. This board is very suitable for learners that want to learn STM32 microcontroller with ARM Coretex-M3 32-bit core.

Features

On-board SWD interface, and it can be programmed with ST-LINK V2.
On-board reset button and power indicator LED.
On-board test indicator LED, and the beginners can program to control it.
On-board 100mA 3.3V Regulator.
Operating voltage: 3.3 V.
IO logic voltage: 3.3V
Digital I/O Pins: 37.
Analog Input Pins: 10 (12bits).
USB interface:1
Flash Memory: 32KB.
SRAM: 10KB.
Programmable Clock Speed: 72 MHz (MAX).
Model: STM32F103C6T6
Core: ARM 32 Cortex-M3 CPU.
Debug mode: SWD.
72MHz work frequency.
Reset(POR/PDR).
4-16MHz crystal.
On-board Mini USB interface, you can give the board power supply and USB communication.
