UTC LM324 Quad Operational Amplifiers

SKU: RZ24341446 Category: General

₹ 23.64

Out of Stock

Buy UTC LM324 Quad Operational Amplifiers online, Order today to get instant delivery in all over india.

Bulk Discount Pricing

Quantity	Discount	Price / Unit
5 – 10	2%	₹ 23.17
11 – 30	3%	₹ 22.93
31 – 50	4%	₹ 22.70
51 – 100	5%	₹ 22.46

Out of Stock

You're on the list! We'll email you when this product is back in stock.

Enter your email to be notified when this product is available again.

Why Buy From Us

Fast Shipping

Quick dispatch on all orders

Secure Payment

100% safe transactions

GST Invoice

Available on all orders

Easy Returns

7-day return policy

Expert Support

Always here to help

Product Details

Category General

Subcategory General

SKU RZ24341446

The UTC LM324 consists of four independent, high gain internally frequency compensated operational amplifiers which are designed specifically to operate from a single power supply over a wide voltage range. Operation from split power supplies is also possible. Application areas include transducer amplifier, DC gain blocks and all the conventional OP amp circuits which now can be easily implemented in a single power supply system.

FEATURES

Internally frequency compensated for unity gain.
Large DC voltage gain :100dB.
Wide operating supply range (Vcc=3V~40V).
Input common-mode voltage includes ground.
Large output voltage swing: From 0V to Vcc-1.5V.
Power drain suitable for battery operation.

Datasheet

Specifications

Model	LM324
Brand	UTC
Supply Voltage	±20V
Differential Input Voltage	±40V
Power Dissipation	800mW
Package	DIP-14
Operating Temperature	-20°C to 85°C
Quantity	100
Country of Origin	China
