Winsen ZE11 Electrochemical Detection Module For ETO

ZE11 is a general-purpose and high-performance electrochemical module. It can detect the benzene, dimethyl benzene, ethylene, chloro ethylene based on electrochemical principle, it has good selectivity and stability. A temperature sensor is built-in for temperature compensation.

It has the digital output and analog voltage output at the same time which facilities the usage and calibration and shorten the development period. It is a combination of mature electrochemical detection principle and sophisticated circuit design, to meet customers’ different detection needs.

Application

Petroleum and chemical industry, environment protection filed, detection of benzene dimethyl benzene ethylene oxide chloro ethylene and vinyl benzene

Features:

1. High sensitivity & resolution
2. Low power consumption & long working life
3. UART and analog voltage output
4. Good stability and excellent anti-interference ability
5. Temperature compensation and excellent linear output

Specifications:

1. Model No: ZE11
2. Target Gas: benzene dimethyl benzene ethylene oxide, chloro ethylene
3. Preheat time: ≤3 Min
4. Response time: ≤60 Sec
5. Resume time: ≤60 Sec
6. Resolution: ≤0.5 ppm
7. Working Voltage: DC 5.0V±0.1V
8. Output Data: DAC(0.4～2V), standard voltage signal, UART Output, Sensor amplified voltage signal
9. Working Life: 2 years
10. Operating Environment Temp: -20～50℃
11. Humidity: 15%RH-90％RH (no condensation)
12. Storage Environment Temp: 20～25℃
13. Dimension: Ø32mm x 31.2mm

Packages Includes:

1 x  Winsen ZE11 Electrochemical Detection Module For ETO
