10,000ppm MH-Z16 NDIR CO2 Sensor

The Grove – CO2 Sensor Module is an infrared CO2 sensor with high sensitivity and high resolution. Infrared CO2 sensor MH-Z16 is a universally applicable, small sensor that enables the use of non-dispersive infrared (NDIR), which is available in principle of the Air CO2 Detect, with good selectivity, oxygen-dependent, long service life, built-in temperature sensor , Temperature compensation with UART output, easy to use. It can be widely used in HVAC and indoor air quality monitoring, industrial process monitoring and security, agriculture and animal production.

Application:

MH-Z16, NDIR CO2 gas sensor module, is mostly used in the teaching equipment.

Features:

1. High sensitivity, High resolution, Low power consumption
2. Output method: UART, PWM wave
3. Quick response, Good stability
4. Temperature compensation,
5. Excellent linear output
6. Long lifespan
7. Anti-water vapour interference
8. No poisoning

Specification:

1. Measurement of the range from 0-2000 parts per million (PPM)
2. Resolution of 1 PPM 0-2000 parts per million (PPM)
3. Accuracy of 200 PPM
4. A warm – Operating time 3 minutes
5. Response time <90s
6. Operating temperature: 0. 50 ° C
7. Operating humidity 0% ~ 90% RH
8. Storage temperature: -20 … 60 ° C
9. Operating voltage: 4.5 V to 6 V DC
10. The current maximum current of less than 100 ma, the average current of less than 50 ma.

Package Includes :

1 x 10,000ppm MH-Z16 NDIR CO2 Sensor
