1.5mm Series 2Pin AMP Super Seal Waterproof Female Wire to Wire Automotive Connector

The 1.5mm Series 2Pin AMP Super Seal Waterproof Female Wire to Wire Automotive Connector offers a reliable and secure solution for electrical connections in automotive applications. With a robust design, this connector is rated for currents of up to 15 amps, making it suitable for a wide range of automotive electrical applications. Whether you're connecting sensors, lights, or other essential components, this connector can handle the task with ease.

The 1.5mm Series 2Pin AMP Super Seal Waterproof Female Wire to Wire Automotive Connector is a dependable and versatile solution for automotive electrical connections. Housings assemblies for receptacle contacts, 1 to 6 positions, with sealing gasket and anti-backout device which warns if a contact is not correctly inserted in housing and doesn’t allow the gasket to slip-off during the unmating operation.

Specifications:

• Connector Series: 1.5mm Series
• Number of Pins: 2
• Contact System: AMP Super Seal Double Spring, Stamped & Formed
• Maximum Current Rating: 15 amps
• Housing Assemblies: 1 to 6 positions
• Sealing Gasket: Included for environmental protection
• Material: PA66+GF
• Application: Automotive electrical connections
• Gender: Female
• Mounting Type: Wire to Wire
• Material: Durable and waterproof construction
• Operating Voltage (VAC): Suitable for automotive voltage requirements
• Operating Voltage (VDC): Suitable for automotive voltage requirements
• Temperature Range: -40°C to 125°C
• Pitch: 6 mm
• Orientation: Straight
• Termination: Crimp

Package Includes:

1 Set of 1.5mm Series 2Pin AMP Super Seal Waterproof Female Wire to Wire Automotive Connector.
