ADS1115IDGST – 16-Bit 860SPS 4-Ch Delta-Sigma ADC PGA Oscillator Vref Comparator I2C 10-Pin VSSOP (Texas Instruments)

The  ADS1115 device (ADS111x) is a precision, low-power, 16-bit, I2Ccompatible, analog-to-digital converters (ADCs) offered in an ultra-small, leadless, X2QFN-10 package, and a VSSOP-10 package. The ADS111x devices incorporate a low-drift voltage reference and an oscillator. The ADS1114 and ADS1115 also incorporate a programmable gain amplifier (PGA) and a digital comparator. These features, along with a wide operating supply range, make the ADS111x well suited for power- and space-constrained, sensor measurement applications.

Application:

1. Portable Instrumentation
2. Battery Voltage and Current Monitoring
3. Temperature Measurement Systems
4. Consumer Electronics
5. Factory Automation and Process Control

Features:

1. Single-Cycle Settling
2. Internal Low-Drift Voltage Reference
3. Internal Oscillator
4. Programmable Comparator

Features:

1 x ADS1115IDGST – 16-Bit 860SPS 4-Ch Delta-Sigma ADC PGA Oscillator Vref Comparator I2C 10-Pin VSSOP
