AO3401 30V 4A P-Channel MOSFET SOT-23 by Alpha & Omega
Buy AO3401 30V 4A P-Channel MOSFET SOT-23 by Alpha & Omega online, Order today to get instant delivery in all over india.
Out of Stock
You're on the list! We'll email you when this product is back in stock.
Enter your email to be notified when this product is available again.
The AO3401 P-Channel MOSFET by Alpha & Omega uses advanced trench technology to provide outstanding RDS(ON), low gate charge, and operation with gate voltages as low as 2.5V. This device is appropriate for use as a load switch or in PWM applications.
Features
- VDS (V) = -30V
- ID = -4.2 A (VGS = -10V)
- RDS(ON) < 50mΩ (VGS = -10V)
- RDS(ON) < 65mΩ (VGS = -4.5V)
- RDS(ON) < 120mΩ (VGS = -2.5V)
Specification
| Model | AO3401 |
| Brand | Alpha and Omega |
| Drain-Source Voltage (VDS) | -30V |
| Gate-Source Voltage (VGS) | ±12V |
| Continuous Drain Current | -4A to -3.2A |
| Pulsed Drain Current | -27A |
| Operating Temperature | -55°C~150°C |
| Package | SOT23 |
| Quantity | 10 |
| Country of Origin | China |
