BPW34 Silicon PIN Photodiode
Buy BPW34 Silicon PIN Photodiode online, Order today to get instant delivery in all over india.
Out of Stock
You're on the list! We'll email you when this product is back in stock.
Enter your email to be notified when this product is available again.
BPW34 is a PIN photodiode with high speed and high radiant sensitivity in miniature, flat, top view, clear plastic package. It is sensitive to visible and near infrared radiation. BPW34S is packed in tubes, specifications like BPW34.
Features:
- Package type: leaded
- Dimensions (L x W x H in mm): 5.4 x 4.3 x 3.2
- Radiant sensitive area (in mm2): 7.5
- High photo sensitivity
- High radiant sensitivity
- Suitable for visible and near infrared radiation
- Fast response times
- Angle of half sensitivity: ϕ = ± 65°
- Compliant to RoHS Directive 2002/95/EC and in accordance to WEEE 2002/96/EC
Application: High speed photo detector.
Specifications:
| Product Type | Photodiode PIN |
| Peak Wavelength | 1100 nm |
| Lens Type | Blue |
| Half Intensity Angle Degrees | 65 |
| Maximum Collector Current | 2 nA |
| Mounting | Through Hole |
| Pins | 2 |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 100°C |
Package Includes:
1 x BPW34- PHOTODIODE
