CD40106 Hex Schmitt Trigger Inverter IC DIP-14 Package (NFC) Transceiver IC

The CD40106B device consists of six Schmitt-Trigger inputs. Each circuit functions as an inverter with Schmitt-Trigger input. The trigger switches at different points for positive- and negative-going signals. The difference between the positive-going voltage (VP) and the negative-going voltages (VN) is defined as hysteresis voltage (VH). The CD40106B device is supplied in ceramic packaging (J) as well as standard packaging (D, N, NS, PW). All CD40106B devices are rated for –55°C to +125°C ambient temperature operation.

Applications:

1. Wave and Pulse Shapers
2. High-Noise-Environment Systems
3. Monostable Multivibrators
4. Astable Multivibrators

Features:

1. Noise Immunity Greater Than 50%
2. No Limit On Input Rise and Fall Times
3. Standardized, Symmetrical Output Characteristics
4. For Quiescent Current at 20 V
5. Compact Size
6. Color: Black

Packages Includes:

1 x CD40106 Hex Schmitt Trigger Inverter IC
