Connectwell PTB35/50 50 sq mm Stud Type Power Terminal Blocks

SKU: RZ24338319 Brand: Connectwell Category: General

₹ 108.40

Out of Stock

Buy Connectwell PTB35/50 50 sq mm Stud Type Power Terminal Blocks online, Order today to get instant delivery in all over india.

Bulk Discount Pricing

Quantity	Discount	Price / Unit
5 – 10	2%	₹ 106.23
11 – 30	3%	₹ 105.15
31 – 50	4%	₹ 104.06
51 – 100	5%	₹ 102.98

Out of Stock

You're on the list! We'll email you when this product is back in stock.

Enter your email to be notified when this product is available again.

Why Buy From Us

Fast Shipping

Quick dispatch on all orders

Secure Payment

100% safe transactions

GST Invoice

Available on all orders

Easy Returns

7-day return policy

Expert Support

Always here to help

Product Details

Brand Connectwell

Category General

Subcategory General

SKU RZ24338319

The Connectwell PTB35/50 is a 50 mm² Feed Thru Barrier Type Bolt Terminal BLOCK. PTB series Terminal Blocks are recommended for applications involving large cross-section wires. The wire is crimped to a ring/fork lug and screwed onto the Terminal Block's flat current bar. Specially designed Mounting Feet secure the Terminal Block to the Mounting Rail. Two Lugs of the rated cross-section can be connected to the Terminal Block without adversely affecting the Terminal Block's safety. A hinged protective cover on the PTB35SH and PTB70SH Terminal Blocks makes the Terminal Block shockproof (finger safe) and has a marker recess to accept a marking tag.

Datasheet

Specifications

Rated Voltage	1000V
Housing Material	Polyamide
Rated Current	150A
Tightening Torque	3 Nm
Product Function	Power Terminal Block
Wire Entry Orientation	Side Entry
Mounting Possibilities	DIN 35/DIN 35-15 Rail
Screw Size	M6
Operated by	Nut Driver
Rated Surge Voltage	8 kV
Pollution Degree	3
