Degson 2 Pin 5.08 mm Pitch Pluggable type PCB Terminal Block

Degson 2 Pin 5.08 mm Pitch Pluggable type PCB Terminal Block is designed to be inserted into a corresponding female connector, allowing wires to be easily plugged in and removed from the terminal block without the need for any tools.

This type of terminal block is often used in applications where there is a need for quick and easy connection and disconnection of wires, such as in prototyping or in situations where components need to be frequently replaced or reconfigured.

Specifications and Features:

1. Number of pins: 2
2. Mounting Type: Pluggable
3. Pitch: 5.08 mm
4. Rated voltage: 320V
5. Rated current: 20A
6. Wire range: 28-14 AWG
7. Contact resistance: 40mΩ max
8. Operating temperature range: -40°C to 105°C
9. Material: Housing: PA44, UL94V-0
10. Contact: Brass, Tin-plated

Package Includes:

1 xDegson 2 Pin 5.08 mm Pitch Pluggable type PCB Terminal Block
