HONEYWELL CURRENT SENSOR, -100A TO 100A, SOURCE

MICRO SWITCH CS series linear current sensors incorporate our 91SS12-2 and SS94A1linear output Hall effect transducer (LOHETTM). The sensing element is assembled in a printed circuit board mountable housing. This housing is available in four configurations as shown in mounting dimension figures 1, 1a, 2, and 2a. Normal mounting is with 0.375 inches long 4-40 screw and square nut (not provided) inserted in the housing or a 6-20 self-tapping screw. The combination of the sensor, flux collector, and the housing comprises the holder assembly. These sensors
are ratiometric.

Applications: Motor Drive & Control, Safety, Sensing & Instrumentation, Robotics, Power Management, Communications & Networking, Automotive, Metering

Features:

1. Linear output
2. AC or DC current sensing
3. Through-hole design
4. Fast response time
5. Output voltage isolation from input
6. Minimum energy dissipation
7. Maximum current limited only by conductor size
8. Adjustable performance and built-in temperature compensation assures reliable operation
9. Accurate, low-cost sensing
10. Operating temperature range –25 to 85°C
11. Housing: PET polyester

Specifications:

1. Sensor Output: Voltage
2. Supply Voltage DC Min: 6V
3. Supply Voltage DC Max: 12V
4. Current Measuring Range DC: -125A to 125A
5. Current Measuring Range AC: -125A to 125A
6. Response Time: 3µsProduct
7. Range: CSLA SeriesFor Measuring: AC/DC
8. Sensor Type: Hall Effect, Open Loop
9. Current – Sensing: 100A
10. Number of Channels: 1
11. Output: Ratiometric, Voltage
12. Sensitivity: 29.7mV/N

Package Includes:

1 x Honeywell Hall Current Sensor -100A to 100A Source Micro Switch
