KS42STH34-1504A NEMA17 2.2kg-cm Stepper Motor- D-Type Shaft

A stepper motor is a type of DC motor that works in discrete steps. It is a synchronous brushless motor where a full rotation is divided into a number of steps. The two main components of a stepper motor are the rotor and the stator.

Applications:

1. Computer printers
2. Plotters
3. Slot machines
4. CNC machines
5. 3D printers.
6. Robots

Features:

1. Power full Stepper motor
2. Best for your School & collage projects
3. Light wight
4. Highly Precise working
5. Small in size
6. Plug & play device

Specifications:

1. Movement angle: 1.8 degrees
2. Resistance / phase: 1.5Ω
3. Current / phase: 1.5 A
4. Holding torque: 0.22 Nm
5. Inductance / phase: 2.8 mH
6. Weight: 0.22 kg
7. Diameter of the shaft 5mm
8. Dimensions: 42mm x 42 mm x 34 mm (L x W x W)

Packages Includes:

1 x KS42STH34-1504A NEMA17 2.2kgc-cm Stepper Motor – D-Type Shaft
