LM393 Low Power Low Offset Voltage Dual Comparator – SMD

The LM393 series are dual independent precision voltage comparators capable of single or split supply operation. These devices are designed to permit a common mode range−to−ground level with single supply operation. Input offset voltage specifications as low as 2.0 mV make this device an excellent selection for many applications in consumer, automotive, and industrial electronics.

Features:

1. Very Low Current Drain Independent of Supply Voltage: 0.4 mA
2. Input Common Mode Range to Ground Level
3. Differential Input Voltage Range Equal to Power Supply Voltage
4. Output Voltage Compatible with DTL, ECL, TTL, MOS, and CMOS
   Logic Levels
5. ESD Clamps on the Inputs Increase the Ruggedness of the Device
   without Affecting Performance
6. NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP Capable
7. These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
   Compliant

Specifications:

1. Wide Single−Supply Range: 2.0 Vdc to 36 Vdc
2. Split−Supply Range: ±1.0 Vdc to ±18 Vdc
3. Low Input Bias Current: 25 nA
4. Low Input Offset Current: 5.0 nA
5. Low Input Offset Voltage: 5.0 mV (max) LM293/393
6. Wide Single−Supply Range: 2.0 Vdc to 36 Vdc
7. Split−Supply Range: ±1.0 Vdc to ±18 Vdc

Packages Includes:

1 x LM393 Low Power Low Offset Voltage Dual Comparator – SMD
