M5Stack Time-of-Flight Distance Ranging Sensor Unit (VL53L0X)

TOF that employs time-of-flight techniques to resolve distance between the emit point and the reach point of a subject, measuring the round trip time of an artificial light signal provided by a laser.

This unit integrated a distance measuring sensor VL53L0x providing accurate distance measurement whatever the target reflectance, unlike conventional technologies. It can measure absolute distances up to 2m in less than 30ms.

The VL53L0X is a new generation Time-of-Flight (ToF) laser-ranging module housed in the smallest package on the market today, providing accurate distance measurement whatever the target reflectance unlike conventional technologies. It can measure absolute distances up to 2m, setting a new benchmark in ranging performance levels, opening the door to various new applications. The VL53L0X integrates a leading-edge SPAD array (Single Photon Avalanche Diodes) and embeds ST’s second generation Flight Sense  TM patented technology. The VL53L0X’s 940nm VCSEL emitter (Vertical Cavity Surface-Emitting Laser), is totally invisible to the human eye, coupled with internal physical infrared filters, it enables longer ranging distance, higher immunity to ambient light and better robozarstness to cover-glass optical cross-talk. www.st.com

Applications:

1. 1D gesture recognition
2. Laser Ranging
3. 3D structured light imaging（3D sensing）
4. Camera assist (ultra fast autofocus and depth of field)

Features:

1. High precision
2. Measure absolute distances up to 2m
3. The wavelength of laser: 940nm
4. Program Platform: Arduino, UIFlo (Blockly, Python)
5. Two Lego-compatible holes
6. This unit communicates with M5Core via I2C(0x29)
7. Fully integrated miniature module
8. Ranging sensor with advanced embedded micro controller
9. Fast, accurate distance ranging
10. Operates in high infrared ambient light levels
11. Advanced embedded optical cross-talk compensation to simplify cover glass selection

Packages Includes:

1 x M5Stack Time-of-Flight Distance Ranging Sensor Unit (VL53L0X)
