MC3403 Quad Low-Power Operational Amplifier IC DIP-14 Package

The  MC3403 are quadruple operational amplifiers similar in performance to the µA741, but with several distinct advantages. They are designed to operate from a single supply over a range of voltages from 3 V to 36 V. Operation from split supplies also is possible, provided the difference between the two supplies is 3 V to 36 V. The common-mode input range includes the negative supply. Output range is from the negative supply to VCC – 1.5 V. Quiescent supply currents are less than one-half those of the µA741. The MC3403 is characterized for operation from 0°C

Features:

1.  Class AB Output Stage
2.  True Differential Input Stage
3.  Low Input Bias Current
4.  Internal Frequency Compensation
5.  Short-Circuit Protection
6.  Designed to Be Interchangeable With Motorola MC3303

Package Includes:

1 x MC3403 Quad Low-Power Operational Amplifier IC DIP-14 Package
