MICROCHIP  ATTINY817-XPRO  Evaluation Kit, ATtiny817 MCU, Embedded Debugger, Microchip Studio Support

The ATtiny817 Xplained Pro evaluation kit is a hardware platform to evaluate the ATtiny817 microcontroller. Supported by the Atmel Studio integrated development platform, the kit provides easy access to the features of the ATtiny817 and explains how to integrate the device into a custom design. Xplained Pro MCU series evaluation kits include on-board Embedded Debuggers. No external tools are necessary to program or debug the ATtiny817. Xplained Pro extension kits offers additional peripherals to extend the features of the board and ease the development of custom designs.

Attention: For additional technical specifications, please refer to the accompanying datasheet in the attachment section.

Features:

1. ATtiny817 microcontroller
2. Two mechanical user buttons
3. Two QTouch® buttons
4.  One yellow user LED
5.  32.768 kHz crystal
6.  Two Xplained Pro extension headers
7.  Embedded Debugger
   – Auto-ID for board identification in Atmel Studio
   – One yellow status LED
   – One green board power LED
   – Symbolic debug of complex data types including scope information
   – Programming and debugging, including power measurements
   – Data Gateway Interface: SPI, I2C, two GPIOs
   – Virtual COM Port (CDC)
8.  Embedded current measurement circuitry (XAM)
   – Measures power consumption of the ATtiny817 and/or peripherals
   – Measures current between 100 nA and 400 mA
   – Current measurement data are shown in Microchip Data Visualizer
9.  USB powered
10.  Supported with application examples in Atmel Start

Package Includes:

1 x MICROCHIP  ATTINY817-XPRO  Evaluation Kit, ATtiny817 MCU, Embedded Debugger, Microchip Studio Support
