MOC3081M IC – Triac Driver Optocoupler IC

The MOC3081M, MOC3082M and MOC3083M devices consist of a GaAs infrared emitting diode optically coupled to a monolithic silicon detector performing the function of a zero voltage crossing bilateral triac driver. They are designed for use with a discrete power triac in the interface of logic systems to equipment powered from 240 VAC lines, such as solid-state relays, industrial controls, motors, solenoids and consumer appliances, etc.

Applications:

1. Solenoid/Valve Controls
2. Lighting Controls
3. Static Power Switches
4. AC Motor Starters
5. Temperature Controls
6. E.M. Contactors
7. AC Motor Drives
8. Solid State Relays

Features:

1. Simplifies Logic Control of 240 VAC Power
2. Zero Voltage Crossing to Minimize Conducted and Radiated Line Noise
3. 800 V Peak Blocking Voltage
4. Superior Static dv/dt
5. 1500 V/s Typical, 600 V/s Guaranteed

Package Includes:

1 x MOC3081M IC – Triac Driver Optocoupler IC DIP-6 Package

Note:

1. Product Images are shown for illustrative purposes only and may differ from the actual product.
2. For Technical Specifications about the IC go through the Datasheet in the Attachment section.
