MURATA IRA-S210ST01 PIR Sensor, 2 VDC, 15 VDC, 45 °, IRA-S Series

IRA-S series pyroelectric infrared sensor(lead type) deliver high sensitivity and reliable performance made possible by Murata’s ceramic technology. Used mainly in security equipment. Combining performance with low costs, the IRA-S series makes it easier to use pyroelectric infrared sensors in security applications and general consumer equipment. Operating temperature range from -40°C to 70°C .Excellent sensitivity & S/N ratio

Features:

1. Excellent Sensitivity  S/N ratio（Signal/Noise）
2. Excellent Quality
3. Easy to use

Specifications:

1. Operating Temperature Range: -40℃ to 70℃
2. Shape: Lead
3. Field of View: theta1=theta2=45deg.
4. Electrode: (2.0×1.0mm)x2
5. Responsivity(typ.): 4.6mV
6. Optical Filter: 5 micro meter Long Pass
7. Supply Voltage Range: 2V to 15V
8. Storage Temperature Range: -40℃ to 85℃

Package Includes:

1 x IRA-S210ST01 PIR Sensor, 2 VDC, 15 VDC, 45 °, IRA-S Series
