Pic 16F677 Dip – Microchip

The PIC16F677-I/P is a mid-range PIC16 family 8-bit powerful (200 nanosecond instruction execution) yet easy-to-program (only 35 single word instructions) CMOS flash-based Microcontroller packs powerful PIC(RISC) architecture. This product offers all of the advantages of the well-recognized mid-range x14 architecture with standardized features including 3.5kB of addressable program memory size, 128bytes of data memory size, 18 general-purpose I/O pins, two comparators, and a 12-channel 10-bit analog-to-digital (A/D) converter. This device operates at a maximum frequency of 20MHz with a wide operating voltage of 2 to 5.5V.

1. 35 (14-bit wide) easy instructions to learn
2. 8 level hardware stack
3. 1 (9-bit) file select register
4. Hardware interrupt handling
5. 32kHz to 8MHz internal oscillator
6. 256bytes of EEPROM data memory
7. Brown-out Reset (BOR)
8. Power-on reset (POR)
9. Internal voltage reference (Bandgap)
10. One 8-bit digital timer
11. One 16-bit digital timer
12. In-Circuit Serial Programming (ICSP)

Applications

Industrial, Automotive, Consumer Electronics, Motor Drive & Control, Lighting, Medical, Security

Note:

1. Product Images are shown for illustrative purposes only and may differ from the actual product.
2. For Technical Specifications about the IC go through the Datasheet in the Attachment section.


Package Includes:

1 x PIC 16F677 20 MHz 3.5 KB 128 Byte 20 Pins 8-Bit MCU Microcontroller IC
