Ready to sky BN-880 GPS Module

Readytosky GPS BN-880 Antenna Module TTL Level RC Drone. This BN-880 GPS Module can show your speed. When you use it for Raspberry Pi, there is no driver needed. The data output when the TX LED flashing; PPS LED is not bright when GPS is not fixed, flashing in red when fixed

Features:

1. GPS Module,Dual Module Compass
2. With electronic compass IC HMC5883L
3. 1.25mm spacing between the 6pins patch seat

Note:Can not use for flight control with ,but it is  suitable for Open source flight controller

Specifications:

1. Model:BN-880
2. Power Supply: DC Voltage 2.8V~6.0V,Typical:3.3V or 5.0V
3. Consumption: Capture 50mA@5V
4. Receiving Format: GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS
5. Receiving Channel: 72 Searching Channel
6. Receiving Sensitivity: Trace -167dBm Capture-148dBm
7. Level Positioning Precison: 2m At Open Wind
8. Output Frequency: 1Hz-10Hz,Default 1Hz
9. Speed Precison: 0.1 m/s (Without Aid)
10. Acceleration Precison: 0.1 m/s (Without Aid)
11. Working Temperature:-40℃-+85℃
12. Storage Temperature:-40℃-+85℃
13. Weight: 11

Packages Includes:

1x BN-880 GPS Module
1x 15cm Cable
