TLP620-4 Optocoupler/Photocoupler IC
Buy TLP620-4 Optocoupler/Photocoupler IC online, Order today to get instant delivery in all over india.
Out of Stock
You're on the list! We'll email you when this product is back in stock.
Enter your email to be notified when this product is available again.
TLP620-4 is a 16 pin optocoupler IC having four isolated channel as we know that the optocoupler contains photo diode and infrared diodes too so this photocoupler contains photo diode and infrared diode. Optocoupler is used to provide coupling between two isolated circuit it also works as a circuit protector too. Its maximum current transfer ratio is 50%, collector emitter voltage is 55V.
Its used for I/O switching, AC and DC power control, signal isolation and power supply regulation Etc.
Features
-
Its isolation voltage is 5000V
-
Its junction temperature is 125 °C
-
Maximum power dissipation is 100 m W
-
Its collector current is 50mA
-
Lead soldering temperature is 260°C
Specification
| Model | TLP620-4 |
| Type | Optocoupler |
| Pulse forward current | 1A |
| Emitter collector voltage | 7V |
| Collector emitter voltage | 55V |
| Collector current | 50mA |
| Supply voltage | 5 - 24 V |
| Operating and Storage Temperature Range | 85°C |
| Country of Origin | China |
