Waveshare 1.02inch 128×80 black/white dual-color E-Ink display module

 This is a Waveshare 1.02inch 128×80 black/white dual-color E-Ink display module. The E-Ink display module, 1.02inch, 128×80 resolution, with embedded controller, communicating via SPI interface, supports partial refresh. Due to the advantages like ultra-low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf labels, industrial instruments, and so on.

Useful link:

To do Hardware and Software setup, please follow this tutorial.

Features:

1. No backlight keeps displaying last content for a long time even when power down
2. Ultra-low power consumption, basically power is only required for refreshing
3. SPI control interface, for working with host boards such as Raspberry Pi/Jetson Nano/Arduino/Nucleo
4. Onboard voltage translator, compatible with 3.3V/5V MCUs
5. Comes with development resources and manual (examples for Raspberry Pi/Jetson Nano/Arduino/STM32)

Package Includes:

1 x Waveshare 1.02inch 128×80 black/white dual-color E-Ink display module
