Winsen MG812 Mini Size Solid Electrolyte CO2 Gas Sensor

MG812 gas sensor is chemical type gas sensor that adopts solid electrolyte cell principle, used to detect carbon dioxide. When sensors are exposed to CO2, battery is positive and negative electrode reaction, the sensor produces electromotive force between sensitive electrode and reference electrode, the output voltage signal can be detected carbon dioxide.

CO2 Sensors are used to measure the levels of carbon dioxide (CO2). It is important to monitor this gas as it is an indicator of CO2 emission levels, ventilation quality and combustion industrial processes.

Features:

1. Small sizes
2. low power-consumption
3. high sensitivity and good selectivity
4. Less affection by temperature and humidity
5. Steady performance and repeatability

Specifications:

1. Model No: MG812
2. Standard pack: Metal shell
3. Target gas: CO2
4. Detection range: 350—10000ppmCO2
5. Heater voltage: VH 5.0±0.1 V
6. Heater resistance: RH 56.0±3Ω
7. Heater current: IH 90±10mA
8. Heater consumption: PH 450±50mW
9. Working temp Tao: -20～50℃
10. Storage temp: -20～70℃
11. Zero EM F: 200-500mV
12. Output signal EM F: ≧25mV/1000ppmCO2

Packages Includes:

1 x Winsen MG812 Mini Size Solid Electrolyte CO2 Gas Sensor
