YIHUA 939D+ Multifunctional professional welding soldering station

The YIHUA 939D+ multifunctional professional welding soldering station with an added 3-segment parameter storage function that allows users to save preset functions in different temperature ranges for convenient future use. Interchangeable temperature display mode between Celsius and Fahrenheit, adjustable sleep time, auto power-off time, and similar adjustable parameters. Users can quickly retrieve any desired parameter in the next operation.

The system will automatically back up with the previous temperature setting every time when powered on.

Specifications and Features:

1. Rated Voltage: AC 220V±10% 50Hz
2. Total Power: 75W
3. The thermostat power: (rapid PID program-controlled energy saving) 200W±10％
4. Dielectric Voltage Withstand Test: AC1500V 0.4A 60S
5. Working Environment: 0～40℃ relative humidity＜80％
6. Storage Temperature: －20～80℃ relative humidity＜80％
7. Working Voltage: AC 26V±10% 50Hz
8. Temperature Range: 100℃～480℃
9. Temperature Stability: ±1℃ (Static)
10. Display Type: LCD
11. Temperature Correction Method: Digital PID correction
12. PID temperature correction cycle: 100ms
13. Heater: Imported heater
14. Tip to Ground Impedance: ＜2Ω
15. Tip of Ground Voltage: ＜2mV
16. Weight 2KG
17. Dimension: 14.5 x 12 x 8 cm

Package Includes:

1 x YIHUA 939D+ Multifunctional professional welding soldering station
