10.1 inch IPS LCD Touch Screen 1280×800 with Driver Board Kit for Raspberry Pi –

SKU: 1062474
In Stock

8,064.00

  1. Operating voltage: 12V
  2. Current requirement: 1A-2A
  3. Rated power: 6-7W
  4. HDMI input: version HDMI 1.1
  5. VGA input: 1280×800 physical resolution
  6. Brightness: 350 lumens
  7. Panel type: TFT
  8. Display Type: Capacitive Touch Display
  9. Number of wiring: 40 PIN LVDS
  10. Backlight: LED
