SKYRC PC3000H 3000W 60A 12/14S LiPo/LiHV Quattro Battery Charger
₹59,999.00
- Product: SKYRC PC3000H 3000W 60A 12/14S LiPo/LiHV Quattro Battery Charger
- High Performance on Four Channels
- Battery Life Extended with Pre-charge
- Better Protection with Conformal Coating
- Optimized Design through the Convection Air Duct
Did you like this product? Add to favorites now and follow the product.
+91-7231900002 Connect on Whatsapp
Description
It can connect with up to four batteries at the same time. The maximum output power is up to 3000W, and users can choose between four modes of Fast Charge/Standard Charge/Charge/Storage.The charger can recognize the batteries instantly and charge automatically with customized CAN communication. Charging should be a more convenient and straightforward experience. During the charging process, the screen displays charging time, battery percentage, and every single cell’s voltage in real-time
Note: For more technical Details go through Datasheet in the attachment section
Features:
- High Performance on Four Channels
- Battery Life Extended with Pre-charge
- Better Protection with Conformal Coating
- Optimized Design through the Convection Air Duct
- Effectively filtering dust and sediment with a high-quality ventilator
- PC3000H charger comes with the built-in CAN Bus communication
Package Includes:
1 x SKYRC PC3000H 3000W 60A 12/14S LiPo/LiHV Quattro Battery Charger
Additional information
| Battery | Type：Lithium Battery LiPo Battery Cells：12S/14S (4.2V) LiHV Battery Cells：12S/14S (4.35V) |
|---|---|
| At AC 220V | Fast Charge Current: max. 60A single channel Standard Charge Current: max. 30A single channel, max. 60A Dual channels in total Slow Charge Current: max. 20A single channel; max. 60A multi channels in total |
| At AC 120V | Fast Charge Current: max. 1200W single channel Slow Charge Current: max. 20A single channel; max. 1200W multi-channels in total |
| Storage Discharge Power | Main Port: 50W Max. Balance Port: 80W Max. (The current will be adjusted based on the balance port’s temp) |
| Max Charge Output Power | AC220V Output Power: 3000W AC120V Output Power: 1200W |
| Discharge Power | 60W |
| Charging Mode | Fast charge /Standard Charge/ Charge / Storage |
| Working Temperature Range (°C) | 0℃-40℃ |
| Working Humidity Range | 0%-75% |
| Storage Temperature | -10℃-70℃ |
| Storage Humidity | 0%-75% |
