IKSemicon LM2596-ADJ DC-DC Step-Down Voltage Regulator

SKU: RZ24341267 Category: Power Supply & Converters

₹ 58.05

Out of Stock

Buy IKSemicon LM2596-ADJ DC-DC Step-Down Voltage Regulator online, Order today to get instant delivery in all over india.

Bulk Discount Pricing

Quantity	Discount	Price / Unit
5 – 10	2%	₹ 56.89
11 – 30	3%	₹ 56.31
31 – 50	4%	₹ 55.73
51 – 100	5%	₹ 55.15

Out of Stock

You're on the list! We'll email you when this product is back in stock.

Enter your email to be notified when this product is available again.

Why Buy From Us

Fast Shipping

Quick dispatch on all orders

Secure Payment

100% safe transactions

GST Invoice

Available on all orders

Easy Returns

7-day return policy

Expert Support

Always here to help

Product Details

Category Power Supply & Converters

Subcategory Voltage Regulators

SKU RZ24341267

The LM2596 regulator series is a monolithic integrated circuit that provides all of the active operations for a step-down switching regulator capable of driving a 3A load with excellent line and load control. Multiple variants are available for these devices in 3.3V, 5V, and 12V fixed output voltages and an adjustable output variant.
These regulators are simple to operate because they require only a few external components. The switching frequency of the IL2596 series is 150kHz. A standard 5-lead TO220 package is available. Other features include a guaranteed 4% output voltage tolerance under specified input voltage and output load conditions and a 15% oscillator frequency tolerance. External shutdown is provided, with a typical standby current of 100A.

Features

Adjustable output
Adjustable version output voltage range, 1.2V to 37V
± 4% max over the line and load conditions
Guaranteed 3A output load current
Input voltage range up to 40V
Requires only four external components
Excellent line and load regulation specifications
150kHz fixed frequency internal oscillator
TTL shutdown capability
Low power standby mode,
IQ typically 100µA
Thermal shutdown and current limit protection

Applications

Simple, high-efficiency step-down regulator
On-card switching regulators
Positive to negative converter

Datasheet

Specifications

Model	IL2596-ADJ
Brand	IKSemicon
Input Voltage	4.5V-40V DC
Rated Current	0.2-3A
Efficiency	73%
Number of Pins	5
Output Voltage Range	1.23V-37V
Switching Frequency	150 kHz
Package	TO-263
Mounting Type	SMD
Quantity	500
Country of Origin	China
