NC7SZ125M5X – 5.5V TinyLogic UHS Buffer 3-STATE Output 5-Pin SOT-23 (ON Semiconductor)

The NC7SZ125M5X is a single Buffer with three-state output. The device is fabricated with advanced CMOS technology to achieve ultra high speed with high output drive while maintaining low static power dissipation over a very broad VCC operating range. The device is specified to operate over the 1.65 to 5.5V range. The inputs and output are high impedance above ground when VCC is 0V. Inputs tolerate voltages up to 6V independent of VCC operating voltage. The output tolerates voltages above VCC when in the 3-STATE condition. This product is general usage and suitable for many different applications

Features:

1. Power down high-impedance inputs/outputs
2. Overvoltage tolerance inputs facilitate 5 to 3V translation
3. Proprietary noise/EMI reduction circuitry

Specifications:

1. Input Voltage:1.65~5.5V
2. No. of Pins:5
3. Max Power Dissipation:200 mW
4. Quiescent Current:2 uA
5.  Temperature Range:-40 to 85 Degree Celcius

Package Includes:

1 x NC7SZ125M5X – 5.5V TinyLogic UHS Buffer 3-STATE Output 5-Pin SOT-23 (ON Semiconductor)
