AMPHENOL SGX MICS-VZ-89TE.INTEGRATED SENSOR BOARD, 3.3VDC, 0.125W

The MiCS-VZ-89TE combines state-of-the-art MOS sensor technology with intelligent detection algorithms to monitor tVOCs and CO2 equivalent variations in
confined spaces, e.g. meeting rooms or vehicle cabins. The dual signal output can be used to control ventilation on-demand, saving energy and reducing cost-of ownership.

Features:

1. Calibration-free
2. Low power
3. Wide VOCs detection range
4. High sensitivity
5. High resistance to shocks and vibrations

Specifications:

1. Supply Voltage 3.3V DC regulated +/- 5%
2. Operating Power 125 mW
3. Warm-up Time 15 min
4. Operating Temperature 0°C to 50°C
5. Operating Humidity 0%RH to 95%RH (non condensing)
6. Storage Temperature -40°C to 80°C
7. Storage Humidity 0%RH to 95%RH (non condensing)

Package Includes:

1 x AMPHENOL SGX MICS-VZ-89TE. INTEGRATED SENSOR BOARD, 3.3VDC 0.125W
