Connectwell CSTSN5U 16 sq.mm Stud Type Terminal Block in (Grey)
🔍 Zoom

Connectwell CSTSN5U 16 sq.mm Stud Type Terminal Block in (Grey)

SKU: RZ24340141 Brand: Connectwell Category: General
₹ 63.94
Out of Stock

Buy Connectwell CSTSN5U 16 sq.mm Stud Type Terminal Block in (Grey) online, Order today to get instant delivery in all over india.

Bulk Discount Pricing
Quantity Discount Price / Unit
5 – 10 2% ₹ 62.66
11 – 30 3% ₹ 62.02
31 – 50 4% ₹ 61.38
51 – 100 5% ₹ 60.74

Out of Stock

You're on the list! We'll email you when this product is back in stock.

Enter your email to be notified when this product is available again.

Why Buy From Us

Fast Shipping

Quick dispatch on all orders

Secure Payment

100% safe transactions

GST Invoice

Available on all orders

Easy Returns

7-day return policy

Expert Support

Always here to help

Product Details
Brand Connectwell
Category General
Subcategory General
SKU RZ24340141

The Connectwell CSTSN5U is a 16 sq. mm Stud Type Terminal Block in Grey color, This nut driver-operated M5 sized Stud Type Terminal Blocks, with Universal Mounting Possibility. These Terminal Blocks are recommended for applications in which the connections are subjected to high vibrations. The wire is crimped to a ring/fork type Lug (Ferrule) and screwed onto the Terminal Block's flat current bar. Terminal Blocks are available in sizes ranging from 1.5 to 16 sq mm. External shorting links can be used to achieve cross-connection. To completely encase these assemblies, it is advised to use Protective Covers made of transparent plastic.

 Datasheet
Specifications
Rated Voltage 1000V
Housing Material Polyamide
Rated Current 76A

Tightening Torque

2 Nm

Product Function

Feed Through

Wire Entry Orientation

Side Entry

Mounting Possibilities

DIN 32/DIN 35/DIN 35-15 Rail

Screw Size

M5

Operated by

Nut Driver

Rated Surge Voltage

8 kV

Pollution Degree

3



Dimensions

Height with DIN 32 rail

46.3mm

Height with DIN 35 * 15mm rail

48mm

Height with DIN 35 * 7.5mm rail

40.7mm

Length

50mm

Width(Thickness)

17mm

Country of Origin China
