LattePanda V1- 4GB/64GB with Enterprise License

You are viewing a 4GB RAM LattePanda Windows 10 mini PC with 64GB eMMC memory. This model of LattePanda V1 – 4GB/64GB includes an activated edition of Windows 10 Enterprise LTSB.

Based on the full version of Windows 10 Professional, Windows 10 Enterprise LTSB is designed for the professional application market. Not only can you run normal windows applications such as Office, Visual Studio, and Processing.

Via the attached advanced tools such as AppLocker, BitLocker, and Hyper-V, you can also have the highest level of security and management capabilities. From home servers to digital signage, this operating system can be the basis for your next big project.

But Wait! A LattePanda also includes an integrated Arduino compatible co-processor, using hundreds of mature development platforms such as Johnny Five and Cylon, you can easily use it to control and sense the physical world!

Whether you are a Windows developer, IoT developer, DIY fanatic, interactive designer, robotics whizz, or maker, a LattePanda single-board computer can aid your creative process!

Specifications and Features:

1. Intel Cherry Trail Z8350 Quad-Core Processor
2. Base Frequency: 1.44GHz (1.92GHz Burst Frequency)
3. Operating System: Windows 10 Enterprise LTSB x64 with activating key
4. RAM: 4GB DDR3L
5. Storage Capacity: 64GB
6. GPU: Intel HD Graphics, 12 EUs @200-500Mhz, single-channel memory
7. USB 3.0 x 1, USB 2.0 x 2
8. Wi-Fi 802.11n 2.4G
9. Bluetooth 4.0
10. Integrated Arduino Co-processor: ATmega32u4 (Arduino Leonardo)
11. Video output: HDMI and MIPI-DSI
12. Onboard touch panel overlay connector
13. Supports 100Mbps Ethernet
14. Intel Processor GPIO x 6
15. ATmega Processor GPIO x 20
16. Gravity Interface Connectors x 6
17. Voltage: 5V@2A
18. Board Dimensions: 88 x 70mm / 3.46 x 2.76″
19. Package Dimensions: 110 x 94 x 30 mm/4.33 x 3.70 x 1.18″
20. NET Weight: 55g
21. Gross Weight: 100g

Useful Links:

• User Guide
• Github Repository
• 3D Model
• Compliance Certificates
• Pin Mapping

Package Includes:

1 x LattePanda 4G/64GB

1 x WiFi Antenna

1 x Printed Safety Precautions

1 x Windows10 Enterprise LTSB Activate Manual
