Transmission frequency	2.400GHz-2.480GHz
Transmitter module	Option 1: Internal 4-in-1 multi-protocol module (CC2500 CYRF6936 A7105 NRF2401)； Option2: Internal ELRS (SX1280)
Transmitting power	Internal 4-in-1 multi-protocol module : Max 100mw (protocol dependent); Internal ELRS : Max 250mw (transmitting power is adjustable)
Antenna gain	2db (transmit power adjustable)
Working current	400mA
Working voltage	6.6-8.4v DC
Remote control distance	>2km @ 22dbm
Radio firmware	EdgeTX
Module Firmware	Multiprotocol- Module (4IN1) -OR- ExpressLRS (ELRS)
Channels	Up to 16 channels (depending on the receiver)
Display	4.3-inch TFT full-colour touch display with a resolution of 480 x 272
Gimbal	Option 1: V4.0 Hall sensor with Aluminium fascia Option 2: AG01 CNC Hall sensor
Module Bay	JR compatible module bay
Upgrade method	Supports USB-C online / SD card offline upgrade
Dimensions	287 x 129 x 184mm
Weight	750g (without battery)

Module bay	Nano size (Compatible with TBS Nano Crossfire / Nano Tracer / IRC Ghost)
Firmware Upgrade method	Via USB or SD card (SD Not included)
RF power	TBA (CE and FCC Version will be available)
Operating system	OpenTX / EdgeTX Compatible
Control channels	Maximum 16 (Rx dependent)
Operating frequency	2.400GHz-2.480GHz
Physical dimensions	170 x 159 x 108mm
Charging	Built-in USB-C Charging
Display	128 x 64 Monochrome LCD
Operational current	160mA at 8.4V
Operational voltage	6.6-8.4v DC
Battery	2 x 18350 (Not included)
Supported protocols	ELRS
Internal RF Options	ELRS
Antenna gain	Folding 2db
Control distance	TBA
Weight	350 grams
Gimba	Hall-effect
